MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 58 of 138
ensure the bar is back to the closing
position; fasten the safety harness to the
proper eyelets in the basket frame.
The operator who climbs on board the basket
must always have a pointed object (for
example a screwdriver) which, in the event of
an electric/hydraulic emergency on the
machine, can help him to manually push the
cursors for leveling and rotation of basket.
It is forbidden to overload the basket
exceeding its maximum allowed nominal
capacity.
4.4.4 Basket leveling
11. After making sure the light 19 (Picture 12) is
on, level the basket using the platform control
(exercise) station (par. 3.2.1): press both the
dead man button 16 (Picture 11) and the
joystick lever for basket leveling control, in
case the floor is out of level.
Level the basket only when the MEWP aerial
part is set in the transport configuration.
It is strictly forbidden to level the basket with
the machine developed.
4.4.5 Use of the aerial part
12. After making sure the light 20 (Picture 12) is
on, using the platform control (exercise)
station, carry out the MEWP aerial part
operations by the manipulators described in
the paragraph 3.2.1.
First lift the upper boom, in order to rise it from
the support.
It is strictly forbidden to rotate the turret as first
movement, since it could seriously damage
the carpentry.
It is forbidden to enter or exit the work platform
at different levels, when the machine is
developed.
It is forbidden to increase the outreach or
working height of the MEWP by using
additional equipment.
