MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 57 of 138
4.4.2.3 Automatic stabilization with basket
console
The stabilization can also be performed automatically,
from the basket console by deactivating the radio control:
• by means of the basket control station, it is also
possible to perform automatic
stabilization/destabilization with the SAC buttons
(Picture 49).
Picture 49: stabilization/destabilization lever
on basket station control.
• make sure that the consent indicator for the use
of the aerial part 20 (Picture 12) is on.
4.4.3 Access in the basket
Proceed with the basket assembly after having turned off
the machine.
Picture 50: basket coupling.
9. Once the basket is coupled, insert the pin P
and the safety cotter pin C to block it to the jib
support (Picture 50).
10. Enter the basket by lifting the self-locking
closing bar and using the underlying step;
