MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 64 of 138
The emergency button has a mechanical locking device,
therefore, to restore normal working conditions, it must
be unlocked by turning it clockwise.
On the machine, there are emergency buttons in the
following positions:
1. on the right side of the platform command
station (operating position) (Picture 9);
2. on the center of the platform radio control
station (Picture 13);
3. on the left side of the outriggers control station
on the frame (Picture 39).
4.6.2 Emergency bypass
In case the basket operator pressed the emergency
button and were unable to reset this button at the original
position (due to blackout, fainting or other), it will be
possible to disable that safety function through the
“emergency bypass” BP under the yellow cap
(Picture 52) located on the switching on/off box.
The ground operator removes a safety lead seal and
disable the emergency through an internal on/off lever.
Picture 52: emergency bypass lever.
It will be care and responsibility of the operators, at
the end of the operations, to reset the original
conditions, including the resealing with seal
compulsorily branded “C.M.C.”.
4.6.3 Emergency procedure in case of
electrical system failure (PLC)
In case of failure of the electrical system (PLC
breakdown, but standard engine still working), the
machine will go into lockout and on the display (T screen
