MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 65 of 138
- Picture 26) of the radio control the activated error codes
will be displayed.
Remember that below the machine is considered in the
working position with the basket on the rear.
In order to secure the machine, perform the following
procedures in the indicated chronological order:
1. recovery of the aerial part (including levelling and
rotation of basket);
2. closing of the outriggers;
3. narrowing and travel of the tracks.
4.6.3.1 Recovery of the aerial part
Picture 53: view from the right side of
main inlet group.
The ground operator must:
o reach the main inlet group (Picture 53) on the
frame and remove the cover;
