CME BodyGuard 575 Color Vision User Manual

Software ver. CVPCA30E_1 47
BodyGuard® Default Settings
The pump comes programmed with a number of default parameters that can be
viewed using ‘Review Set Up’ from the main menu and changed using the
technician Access Code in ‘Change Set Up’ mode.
PARAMETER
PURPOSE
RANGE
Battery Level
Current battery charge
Empty >> Full
Lock Out
Shows whether access code
security is on or off.
ON/OFF
Time, Date
Tube Temperature
Shows the temperature of the
tubing set
C
Alarm Volume
Volume of alarms/alerts
3-7
Pressure Level
Occlusion Pressure Setting
250mmHg – 520mmHg
(5psi – 10psi )
Priming Volume
Amount of fluid delivered during
set priming.
0-20ml
Default 4 ml
Priming Rate
Rate at which priming occurs.
0-1200 ml/hr.
Default 600 ml/hr
Bolus Rate
Speed at which boluses are
delivered.
According to back
pressure in system – max.
rate 30ml/h
Maximal Basal Rate
Maximum continuous basal rate.
0.1-0.5 ml/hr
KVO Rate
Keep Vein open rate.
Program Limits
Limits in ml, mg, µg or in bolus
Off, 1, 4, or 24 hours.
Air in line limit
Sets the maximum air bubble size
needed to cause an alarm
Off when set to 0.
Indicator Led
Switches the LED indicator
On & Off
ON/OFF
Set Time & Date
Event Log
History Records the last 500 pump
programming events
Fixed data
Serial No.
Serial Number Unique Pump
Fixed data
Production Date
Date of manufacture
Week, month, year
Operation Time
Hours since last service
Software Ver.
Pump software version
Fixed data
Volume Calibration
Volumetric calibration value
Fixed data
Pressure Delta
Pressure calibration Delta value
Pressure CAP
Pressure calibration CAP value
Fixed data – 255
Exit/Restart
Exit/Restart when OK
 NOTE: Only highlighted parameters can be changed (see ‘Change Set Up’)
