4-3-3 Selection of Where to Install
Item Description
Place
- Do not install the compressor unit on the outside.
- Please keep warm during the winter season, if you have to install on the outside.
Space
- Keep the space of more than 31.5inch from the wall to facilitate the repair and
maintenance of the compressor
- Do not place any object in front of the door.
Floor and
Foundation
- The floor shall sufficiently holds the weight of the compressor.
- The floor surface shall be flat with a gradient less than 1 degree to minimize
the vibration.
- It is recommended to install the compressor 4inch above the floor, though
Coaire air compressor generates an insignificant amount of vibration.
Room
Temperature
- Optimal ambient temperature is 32~104 during the operation.
- Install the compressor at low temperature and moisture, if possible.
 Each 18 increase of the inlet temperature reduces the efficiency of the
compressor by 3-4%.
Hazardous
Substances
- Install the compressor at the place where there is the least noxious gas,
hazardous substance and dust. Those foreign substances may cause the damage
of the air compressor.
Electricity
- The electric power shall have at least 150% of the reference margin.
- The range of fluctuation in voltage shall be within ±10%.
Ventilation
- A ventilation fan shall be installed to forcedly ventilate the room, if the room
temperature exceeds 18 more than the outside temperature in the summer.
- For an exhaust duct, set the velocity at 5 m/s, and the static pressure at less than
5 mmAq.
- Install a protective net on the exhaust outlet to prevent birds, rodents and
foreign substances from entering..
- Place the inlet as low as possible.
[table 4-2] Requirements for Where to Install
INSTALLATION
Model
Air Volume
[ ft³/min = CFM ]
Hood Size
[ Inch x Inch ]
CSOF-M3PL(H), CSOF-M5PL(H) 1060 11.8” x 23.6”
CSOF-S8PL(H), CSOF-S10PL(H) 2120 15.8 “ x 31.5”
[ Table 4-1 ] Ventilation Fan Capacity
