Coaire SCROLL CSOF-M3PL/H12 - Operation Procedures; Routine Operation Checklists

19
OPERATION
[ Table 5-1 ] Operation Parameters
Section Model
CSOF-M3PL(H), CSOF-M5PL(H), CSOF-S8PL(H), CSOF-S10PL(H)
Setting Pressure psi 115(Low pressure) / 140(High pressure)
Difference Pressure psi
Stop : 115(Low pressure) / 140(High pressure)
Re-start : 93(Low pressure) / 120(High pressure)
High temp. stop  176 ( @ Airend )
Starting Method
D.O.L
5-2 Routine Operation
5-2-1 Checklists before the Operation
1) Connect the main power to check the display on the monitor.
2) Push the “START” button on the controller to check if the compressor is well started up, and the
indicator lamps are normally on.
3) Check if there is any abnormal vibration, noise and leakage.
4) Check if the operation is in good condition at the maximum load.
Check the following conditions before starting the operation.
Discharge
Pressure
Comp.
Temp
Alarm Message
Lock
Symbol
Operate Status
Target
Pressure
