30
CONTROL
7-4 Error messages
7-4-1 TRIP / ALARM MESSAGE
Item Description Detect condition
1 System Error Parameter Error
2 Emergency stop Push the emergency stop switch
3 Press. Sensor Fault Low Resistance, Short Circuit, Short Circuit to Earth
4 Delivery Pressure High
Detection Pressure >= [ DIS. PRESS LIMIT]
Reset Pressure < [ DIS. PRESS LIMIT -7.25psi ]
5 Comp #1 Fault
Detection [Digital Input :ID1 ] OPEN
Reset [Digital Input : ID1] CLOSE
6 Comp #2 Fault
Detection [Digital Input :ID2 ] OPEN
Reset [Digital Input : ID2] CLOSE
7 Comp #1 Temp.
Detection Comp#1 Temp. >= [COMP TEMP LIMIT]
Reset Comp#1 Temp. >= [COMP TEMP LIMIT] -9
8 Comp #2 Temp.
Detection Comp#2 Temp. >= [COMP TEMP LIMIT]
Reset Comp#2 Temp. >= [COMP TEMP LIMIT] -9
 An trip message is displayed that must be manually reset to clear once the condition has been
resolved or no longer exists.
7-4-2 Alarm condition
Item Description Detect condition
1 RTC(Real Time Clock) Alarm
Detection RTC Disable (When Schedule Mode Operation)
Reset RTC Enable
 An trip message is displayed that will be automatically reset to clear once the condition has been
resolved.
7-4-3 Event massage for operation information
Item Description Detect condition
1 1’ST POWER The time when Initial Power UP to Controller.
2 POWER UP
The time when power up to controller
System restoration by watchdog timer
3 START The time when motor started.
4 STOP The time when motor stopped.
