3-1 Specification
 Note.
1. Noise level is the measurement from acoustic room.
2. The size is the size of the external design of the package. Protruding areas such as discharge ball valve
have been excluded in the measurement.
Model
CSOF-M3PL(H) CSOF-M5PL(H) CSOF-S8PL(H) CSOF-S10PL(H)
UNIT
Type Single Stage Oil Free Scroll Air Compressor
Air
Delivery
(cfm)
115 psi 8.5 14.1 22.6 28.3
140 psi 7.2 12 19.2 24
Driving
Method
Belt 3V-360x2EA 3V-380x2EA
3V-380x2EA
3V-405x2EA
3V-405x4EA
High temp. stop () 176
MOTOR
Output ( kW/HP )
2.2/3 3.7/5
2.2/3 x 1SET
3.7/5 x 1SET
3.7/5 x 2SET
Voltage ( V ) 208-230, 460
Frequency ( Hz ) 60
Poles 4
Starting Method DIRECT ON LINE
GENERAL
Air Outlet (Inch) 1/2” 1”
Receiver Tank (gal)
10
Over 16
(Option)
Over 21
(Option)
Cooling Type Air Cooled
Service air temp. () Intake air temperature +45
Ambient temp. () Max. 104
Noise Level [dB(A)] 49±5 50±5 52±5 53±5
DIMENSION
Length (Inch) 27.5” 25.6”
Width (Inch) 29.1” 45.7”
Height (Inch) 42.1” 51.2”
Weight (Lbs) 275 330 536 587
