Coban 303FG - Product Specifications; Hardware Overview

2
1 Specifications
Product name
GPS Tracker
Model
303FG
DIM.
9.6×5.3×1.6cm
Weight
70g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS sensitivity
-165dBm
GPS accuracy
5m
Time To First Fix
Cold status 45s
Warm status 35s
Hot status 1s
Applicable car power
12V-24V
Battery
Chargeable 3.7V 350mAh Li-ion battery
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +65°C
Humidity
5%--95% non-condensing
2 Hardware Description
3 Terminal Installation
1. Please ask a qualified engineer to install it.
2. The installation environment should ensure that the GSM and GPS signals are good
3. Please do not install it in a dusty and humid environment.
4. Find the 12PIN wiring harness provided with the product, insert it into the corresponding wiring
hole of the product, and connect to the original car circuit as shown in the following Wiring
Diagram:
GPS/POWER/GSM status light
