2201R Mobile Tester User Guide
Chapter 2 Instrument setup and general operation
47090/322
Copyright © 2015 Aeroflex Limited. All rights reserved.
31
Min.
This column shows the minimum (lowest) result for the respective bit class since the test was started.
The statistical evaluation can be restarted by pushing the Reset soft key.
Avg.
This column indicates the average result for the respective bit class since the test was started.
The statistical evaluation can be restarted by pushing the Reset soft key.
Max.
This column shows the maximum (highest) result for the respective bit class since the test was started.
The statistical evaluation can be restarted by pushing the Reset soft key.
Affecting the presentation of results
The test limits can be altered in the Limits menu which can be accessed from the respective basic system menu (the
GSM Tests menu) by pushing Param > Limits.
The statistics can be reset by pushing the Reset soft key. The stored minimum, maximum and average values are
then deleted and the statistical evaluation is restarted.
You can pause the measurement results update by pushing the Freeze soft key. The results update is halted, the last
measurement results remain onscreen and the soft key turns into the Unfreeze soft key.
Push Unfreeze to resume the measurements.
