2201R Mobile Tester User Guide
Chapter 4 Autotest
47090/322
Copyright © 2015 Aeroflex Limited. All rights reserved.
93
Running an Autotest
Connecting the device under test
Follow the instructions in Chapter 2 “Instrument setup and general operation”, in particular ’Connecting the device
under test’ on page32.
Selecting a test
There is a large variety of different types of phones for different cellular standards (such as GSM, GSM-R) and for
different frequency bands on the market. Before measurements can be started, a test must be selected.
To ease the selection, the tests are grouped into different categories. Each Group can have one or more Subgroups,
which in turn consist of individual test scripts.
While the number of tests can easily be extended using Cobham’s 7315 Scriptor, there are already several default
groups and test scripts available with the 2201R Mobile Tester. These tests are (subject to change and amendment):
Abbreviations used:
•GS: GSM standard
• S: single frequency band
• D: dual frequency band
• T: triple frequency band
• Q: quadruple frequency band
• 18: 1800 MHz frequency band
• 19: 1900 MHz frequency band (North America)
Table 13 Default test scripts delivered with the 2201R Mobile Tester
Group Subgroup Test Script
GSM 01.GSM SINGLE-BAND GS_S90.RBT
GS_S18.RBT
GS_S19.RBT
GS_S85.RBT
02.GSM DUAL-BAND GS_D9018.RBT
GS_D8519.RBT
03.GSM TRI-BAND GS_T901819.RBT
GS_T851918.RBT
04.GSM QUAD-BAND GS_Q.RBT
GSM-R MCC-001 MNC-01 DB_V10A.RBT
OEBB_V8A.RBT
GSM_R.RBT
MCC-262 MNC-10 DB_V10A.RBT
OEBB_V8A.RBT
GSM_R.RBT
