3 SINGLE UNIT REPEATER INSTALLATION
This installation is relevant for a single DIGImini unit supporting either a single-band or a dual-band.
3.1 Overview
NOTE: The Donor and Mobile antennas can be positioned and installed (
without being connected to the
Repeater
) at any time either
before
or after
mounting
and grounding the Repeater.
1. Unpack the Repeater kit.
2. Mount the Bracket on the wall, hang the Repeater and Power Supply on the bracket (do not connect
power).
3. Perform the required isolation and link tests.
4. Connect the antennas.
5. Power-on the Repeater.
6. If a DMCU is available, mount the unit (adjacent to the Repeater, on the wall and connect to the
Repeater according to the DMCU User Manual).
3.2 Required Tools and Materials
The following is required in order to install the Repeater:
• Standard professional tool box
• A computer (i.e. laptop for running the setup)
