COBHAM DIGImini - Appendix A: Specifications

DIGIMINI AMERICAS REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage Date: 6-Jul-17 www.cobham.com/wireless
Document number: 00031UM Rev. 6.3
Page |A- 1
Appendix A: Specifications
700 MHz Frequency band Uplink Downlink
Operating Frequency Range
Lower band - 698-716MHz
or
Upper band - 776 - 787MHz
Lower band - 728-746MHz
or
Upper band - 746 - 757MHz
Output power at antenna port
(composite)(*)
21dBm 21dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dB (in 1dB steps) 0-25dB (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise Figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band(**) Up to 8 Up to 8
1700 MHz (AWS1 +3) Frequency band Uplink Downlink
Operating Frequency Range(***) 1710-1780MHz 2110-2180MHz
Output power at antenna port
(composite) (*)
20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dB (in 1dB steps) 0-25dB (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise Figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band(**) Up to 8 Up to 8
850MHz (Cellular) and
SMR 800 (Upper 7MHz) Frequency band
Uplink Downlink
Operating Frequency Range 817-849MHz 862-894MHz
Output
power at antenna port
(composite) (*)
21dBm 21dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dB (in 1dB steps) 0-25dB (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise Figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band(**) Up to 8 Up to 8
1900 MHz (PCS) Frequency band Uplink Downlink
Operating Frequency Range 1850-1915MHz 1930-1995MHz
Output power at antenna port
(composite) (*)
20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dB (in 1dB steps) 0-25dB (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
