DIGIMINI AMERICAS REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage Date: 6-Jul-17 www.cobham.com/wireless
Document number: 00031UM Rev. 6.3
Page |A- 2
Propagation delay 6 μsec 6 μsec
Number of filters per band(**) Up to 8 Up to 8
2600 MHz Frequency band Uplink Downlink
Operating Frequency Range 2500-2570MHz 2620-2690MHz
(composite) (*)
20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dB (in 1dB steps) 0-25dB (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band(**) Up to 8 Up to 8
Electrical specification
Power supply 110/240 VAC
Power consumption <70 Watt for dual band, < 45 W for single band
Environmental specification
Operating temperature range 14 to 122°F
Humidity 85%, ETS 300 019-1-3 Class 3.1
Mechanical specification
Dimensions 11.77” x 12” x 3.03” (b x h x d)
Installation Wall mount
Weight 8.9 lbs for dual band
Ingress protector IP41
Complies with
FCC (NEO-DMINI21082019, NEODMINI2107L2017,
NEODMINI2107U2017)
IC (8794A-DM7L17, 8794A-DM7U17, 8794A-DM819)
(*) 3.5dB less in quad band configurations due to combining loss
(**) Supports every BW option 200kHz-25MHz by setting the start-stop frequency. Total number of filters is 8 in dual
band
(***)Some of the variants supports AWS 1 frequencies only. Please refer to the ordering information for details
