DIGIMINI AMERICAS REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage Date: 6-Jul-17 www.cobham.com/wireless
Document number: 00031UM Rev. 6.3
Page |5-6
5.2 Navigating the Web GUI Application
This section describes how to navigate the Web Management application. The Web Access interface provides
Repeater RF parameters control and monitoring options. The displayed bands depend on the supported
configuration: Dual- or Quad-band configuration.
NOTE: The CMU (Control Monitoring Unit) item in the topology tree is only accessible for sessions opened
via the Digital Monitoring Control Unit (DMCU) - see the DMCU User Manual for details. For sessions
opened by direct connection to a DIGImini front panel, the CMU
item will appear but will not be accessible.
Figure 5-7. Example of Web GUI Screen (shows dual-band)
