The bracket provides two main capabilites:
• Four slots (two bottom and two top) on which to hang the Repeater.
• A step and loops on each side of the bracket for securing the power supply (on any of the sides).
Figure 3-2. Bracket description
3. Hang the Repeater on the Bracket, ridges facing outwards as illustrated below. Use repeater (four) SIDE
screws to hang the Repeater securely on the bracket side slots.
Figure 3-3. DIGImini to Bracket Mounting
