DIGIMINI AMERICAS REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage Date: 6-Jul-17 www.cobham.com/wireless
Document number: 00031UM Rev. 6.3
Page |4-12
4.5.2.4 Combination of Type I and Type II DIGImini Units
NOTE: Assemble the label onto the plate; the relevant bands are on the side of the corresponding repeater.
Figure 4-15.Examples of Plate Used When Both Units are Type-I
Type I Side
