98-145510-E A-1
Appendix A
Technical specifications
A
This appendix has the following sections:
• General specifications
• Antenna specifications
• VSAT LNB Data Sheet (physical LNB)
• VSAT 8W BUC Data Sheet (Extended)
• VSAT 20W BUC Data Sheet (Extended)
• ViaSat eTRIA
• Antenna dimensions
• ACU specifications
• ACU dimensions
A.1 General specifications
Item
Specifications,
EXPLORER 8100
Specifications,
EXPLORER 8120
Certification CE (Safety, EMC & use of spectrum etc.), FCC and IC
(radiation pattern etc.), Eutelsat (pointing, radiation
pattern etc.)
System power supply range
(input via ACU)
100-240 VAC, 50-60 Hz nom.
90-264 VAC, 43-67 Hz max range
Total system power consumption
8 W Ku-BUC
20 W Ku-BUC
3 W Ka-TRIA
160 W typ. 365 W peak
305 W typ. 510 W peak
70 W typ. 270 W peak
180W typ. / 365W peak
325W typ. / 510W peak
N/A
Table A-1: General specifications
