98-145510-E Chapter 7: Service and maintenance 7-7
The upload procedure takes a couple of minutes. When done, the ACU automatically
restarts with the new software version.
Software update (VSAT modem)
Refer to the documentation for your VSAT modem.
7.3 Status signalling with LEDs and status messages
Built-In Test Equipment
The VSAT system has a Built-In Test Equipment (BITE) function in order to make fault
diagnostics easy during service and installation. The BITE test is performed during:
• Power On Self Test (POST), which is automatically performed each time the system is
powered on.
• Person Activated Self Test (PAST), which is initiated by starting a self test in the web
interface HELPDESK > Self test.
For details on error messages after a POST or a self test see Event list on page 7-2.
Means of signalling
The VSAT system provides various methods for signalling the system status.
LEDs on the front panel of the ACU are used to signal:
• Power on/off
• Logon
•Fail/Pass
See LEDs on the keypad of the ACU on the next page.
Display and web interface: In addition to general status messages, the display and the
built-in web interface of the ACU show any events (BITE error codes) with a short message
describing each error.
See System messages on page E-1.
Do not browse away from the upload page. This will terminate the upload
process. Wait for the browser to reload automatically.
