Antenna specifications
98-145510-E Appendix A: Technical specifications A-4
Wind speed - Operational pointing
(0.4 Deg. accuracy)
31 m/s (69 mph) 26 m/s (58 mph)
Wind Speed - Deployed, survival 33 m/s (74 mph) 27 m/s (60 mph)
Wind Speed - Stowed, survival 45 m/s (101 mph) 42 m/s (94 mph)
Vehicle max. velocity
a
(stowed) 130 km/h
Temperature - Operational -33 to +55 °C (-27 to +131 °F)
Temperature - Survival -40 to +80 °C (-40 to +176 °F)
Temperature - Storage -40 to +85 °C (-40 to +185 °F)
Solar radiation 1120W/m
2
to MIL-STD-810F 505.4
b
IP class IP55 dust and spray proof in all directions
Ice survival 5 mm (0.2")
Humidity 0 to 100% (condensing)
Air Pressure, operational 3 km (10000 ft.) AMSL
Air Pressure, transport 4572 m (15000 tf) AMSL, MIL-SPEC-810E 500.4
Shock (handling & transportation) Half sine, 20g/11ms, 3 axis
Rail transport (X & Y horizontal shock) Saw tooth 50g/50ms
a. Note that this specification depends on a number of factors, such as mounting method, wind
speed, terrain etc.
b. Natural convection must be maintained at ambient temperatures > 55°
Environmental characteristics
EXPLORER 8100 EXPLORER 8120
