VSAT 8W BUC Data Sheet (Extended)
98-145510-E Appendix A: Technical specifications A-8
Phase noise 10 Hz dBc/Hz -50
100 Hz dBc/Hz -60
1 kHz dBc/Hz -70
10 kHz dBc/Hz -80
100 kHz dBc/Hz -90
1 MHz dBc/Hz -110
IMD3 At 2 x +33 dBm
carriers
dBc -26
External ref. freq. (input) Nominal MHz 10,000000
External reference freq.
(input)
Deviation Hz -100 0 100
Power supply voltage DC V 20.0 50.0
Supply power DC W 85
Parameter Condition/remark Unit Min. Typical Max.
Table A-7: Technical specifications for VSAT 8 W BUC 2/3 (Continued)
Parameter Condition/remark Unit Min. Typical Max.
Temperature range Operation w. external
forced cooling
°C -30 75
Storage °C -40 85
Dimensions L mm 176
Wmm 170
Hmm102
Weight Total g 2790
Table A-8: Technical specifications for VSAT 8 W BUC 3/3
