VSAT 20W BUC Data Sheet (Extended)
98-145510-E Appendix A: Technical specifications A-10
Spurious/harmonics out RX band 10.70 - 12.75 GHz dBm -56
13.50 - 13.75 GHz band dBm -15
TX band 13.75 - 14.50 GHz dBm -15
14.50 - 14.80 GHz band dBm -17
Carrier ±10 MHz to 9.99 MHz dBm -30
Carrier ±10 MHz to 50 MHz dBm -30
Out of band
a
1) dBm -26
ACPR at Pout 43.0 dBm,
5Msym/s
8PSK, =0.2, f=6Mz, 55°C dBc -24
8PSK, =0.2, f=6Mz, 55°C dBc -24
External ref. freq. (input) Nominal MHz 10
External reference freq.
(input)
Deviation Hz -100 0 100
LO phase noise (output), SSB 10 Hz dBc/Hz -50
100 Hz dBc/Hz -60
1 kHz dBc/Hz -70
10 kHz dBc/Hz -80
199 kHz dBc/Hz -90
1 MHz dBc/Hz -110
a. 0.10 - 10.70 GHz & 12.75 - 13.50 GHz & 14.80 - 26.00 GHz
Parameter Condition/remark Unit Min. Typical Max.
Table A-10: Technical specifications for VSAT 20 W BUC 2/3 (Continued)
Parameter Condition/remark Unit Min. Typical Max.
Power supply voltage DC V 39.0 50
Supply power DC W 185
Temperature range Operation w. internal forced
cooling (no sun)
°C -30 +70
Storage °C -40 85
Table A-11: Technical specifications for VSAT 20 W BUC 3/3
