Supported commands
98-145510-E Appendix D: Command line interface D-5
D.2.5 calib
antenna_data lnb
[<type> [<parameters>]]
Sets the lnb data.
Valid range:
<type> = standard, njr2841 or custom
<parameters> = <lnbparam> [<lnbparam>]
<lnbparam> = <tone> <vol> <lo> <band_l>
<band_h>
• <tone>: LNB tone [0-1]
• <vol>: LNB voltage [130-185] in 0.1V steps
• <lo>: LNB LO [9000000-18000000] in kHz
• <band_l>: LNB band low limit [10000000-
30000000] in kHz
• <band_h>: LNB band high limit [10000000-
30000000] in kHz
Example: To set LNB data to custom "two band LNB with LO
9.75 GHz and 10.75 GHz and voltage selection of
band", enter:
antenna_data lnb custom 0 130 9750000
10700000 11700000 0 180 10750000 11700000
12750000
antenna_data type
Shows the antenna type
antenna_data type
[<type> [<pol_zero>]]
Sets the antenna type
Valid range:
<type> = Ku or eTRIA (Ku must be followed by
<pol_zero>)
<pol_zero> = Pol axis zero value [0-36000]
Command Description
calib
Shows the sub commands, unit and description for the
command calib
calib aenc <mask>
Starts absolute encoder calibration
<mask> defines axes to calibrate, subset of aep
Table D-8: UCLI command: calib
Command Description
Table D-7: UCLI command: antenna_data (Continued)
