Appendix A
AAAAA
Specifications
Specifications A
SAILOR 4300 L-Band System
Item Specification
Weight, BDU 3.5 kg
Weight, BDU, 19” 3.8 kg
Weight, ADU 9.5 kg
Dimensions, BDU 48 x 27 x 4 cm
Dimensions, BDU, 19” 48 x 49 x 4 cm
Dimensions, ADU ø=38 cm, H=37 cm
Minimum safety distance 0.7 m
APPROVALS
Iridium NEXT approved. Compliant to RED, CE Marked. Tested to FCC part 25
FREQUENCY BAND
Operating frequency range 1616 - 1626.5 MHz
Number of channels 30 sub bands + 0.5 MHz paging
Channel spacing 333.333 kHz
Output power 15.4 dBw
Bandwidth 41.667 kHz, 83.333 kHz, 333.333 kHz,
666.666 kHz
ITU Emission Designator 41K7Q1W,83K3Q1W,333KQ1W,333KQ7W,66
6KQ7W
Type of radio transmission Frequency divide and multi carrier
