Appendix A: Specifications
SAILOR 4300 L-Band System 29
AAAAA
Specifications
VIBRATION (ADU)
Vibration, operational Random spectrum 0.92 g rms x 3 axes: 5 to 20
Hz: 0.01 g²/Hz 20 to 500 Hz:
-3 dB/octave
Vibration, non-operational Random spectrum 1.7 g rms 2 h x 3 axes (6 h
total): 5 to 20 Hz: 0.05 g²/Hz, 20 to 150 Hz: -3
dB/octave
SHIP MOTION
Roll +/- 30 deg. per 8 s, max. 0.5 g tan.
Pitch +/- 15 deg. per 6 s, max. 0.5 g tan.
Yaw +/- 10 deg. per 50 s, max. 0.2 g tan.
Surge +/- 0.2 g
Sway +/- 0.2 g
Heave +/- 0.5 g
Turning rate +/- 6°/s; ACC 1°/s²
Headway speed 15 m/s (30 knots)
Wind 200 km/hr (108 knots)
MECHANICAL SHOCK
Mechanical shock 20g/11 half-sine
ANTENNA CONNECTOR
ADU TNC, female
BDU TNC, female
OTHER SPECIFICATIONS
Standard IP data rate, up/down 176/352 kbps
Ethernet/LAN 4 ports
I/O connector 1 connector
Item Specification
