Appendix A: Technical specifications
98-141368-A 112
Minimum distance to transmitters
The table below shows the minimum recommended distance to transmitters in the frequency
range below 1000 MHz.
Recommended distance to SAILOR Fleet One antenna.
Ship motions (MAX) Roll: 30°, period 4 sec., 0.7 g tangential
Pitch: 15°, period 3 sec., 0.6 g tangential
Yaw: 10°, period 5 sec., 0.3 g tangential
Surge: 0.5 g
Sway: 0.5 g
Heave: 0.7 g
Turning rate: 36°/s; 12°/s
2
Headway: 22 m/s (42 knots)
Item Specification
