Appendix A: Technical specifications
98-141368-A 114
SAILOR Fleet One terminal
General specifications
Item Specification
Weight 2.2 kg (4.9 lbs)
Dimensions 231 mm x 278 mm x 41 mm
(9.1” x 10.9” x 1.6”)
Global services
Voice
Data
SMS
4kbps AMBE+2
Up to 100 kbps
2-wire telephone
interface
One connector: RJ-11 female. 600 Ohm ITU-T Rec.
G.473, standard DTMF telephone.
Supported cable length: up to 100 meters.
LAN interface Two connectors: RJ-45 female 10/100 Mbps.
Supported cable length: up to 100 m
PoE (max. 15.4 W) on each port, Total PoE power:
32 W. Conforms with IEEE 802.3 af
I/O interface
Output:
Open switch hold-off
voltage
Open circuit
resistance
Closed switch voltage
Input:
Input resistance
Voltage
Voltage High
Voltage Low
One connector with 5 configurable inputs/outputs.
Open collector, Short circuit protected at 1.5 A and
reverse polarization protected.
max. 32 V
min. 130 kOhm
max. 1 V DC at 50 mA
min. 130 kOhm
Max. 32 V
Min. 2.2 V
Max. 1.2 V
