Maintenance
5-16 HF SSB Transceiver 9323/9360/9390/9780 Technical Service Manual
Control keypad
If there is a lack of response to button selections, it may be due to the malfunction
of one or more of the sealed membrane switches. To test the switches,
disassemble the control head and disconnect J1 [1 04-02974] and remove the
Display Panel PCB. Connect a meter between each pair of pins as indicated in
Table 5-6. An open circuit should appear if the switch is not operated and
continuity (less than 100 Ω) when the switch is pressed.
Table 5 -6: Keypad connections
J1 Connector Switch PCB Button Function
1 - 5 1 - 6 On–Off
1 - 6 1 - 4 F1
1 - 7 1 - 2 Mode
2 - 5 3 - 6 Emgcy Call
2 - 6 3 - 4 USB/LSB
2 - 7 3 - 2 F2
3 - 5 5 - 6 Voice Mute
3 - 6 5 - 4 Tune
3 - 7 5 - 2 –
4 - 5 7 - 6 S'Call Mute
4 - 6 7 - 4 Scan
4 - 7 7 - 2 –
If any of these switches are faulty you need to replace the entire keypad.
Displayed error messages
Message Description
ALE ACK timeout Failure to communicate with ALE Controller
9300/9600.
ALE not initialised The transceiver has not downloaded its
information to the ALE Controller
9300/9600.
BAD ALE ACK Failure to communicate with ALE Controller
9300/9600.
Bad record type XX Data was corrupted during XP programming.
Bad type/inst XX/XX The transceiver detected an internal data
fault.
