HF SSB Transceiver 9323/9360/9390/9780 Technical Service Manual 8-1
8 Parts list
General information
The parts lists for the PCB assemblies contain:
• circuit reference number
• descriptions, giving the value and type of component
• manufacturer and manufacturer’s part number
• Codan part number
©
Items having numeric references identifying specific components or subassemblies
may be encountered in the parts lists included in this manual. These items, selected
from master manufacturing information, identify parts that are either useful for
maintenance purposes or relate to other items and may be cross-referenced in the
remarks column.
Table 8 -1: Resistor and capacitor abbreviations
Resistors Capacitors
CC: carbon composition AS: solid aluminium electrolytic
CF: carbon film CC: ceramic multilayer chip
MF: metal film CE: ceramic
MG: metal glaze EL: wet aluminium electrolytic
MO: metal oxide M: stacked mica
WW: wire wound PC: polycarbonate
PE: polyester
PP: polypropylene
PS: polystyrene
PT: PTFE
TA: solid tantalum
