Codan 9323 Service Manual

Adjustments
7-8 HF SSB Transceiver 9323/9360/9390/9780 Technical Service Manual
All channels have the following enabled:
• USB/LSB/AM
• Emergency Call
• Selcall
• Two-tone
Test channels for 2.25 to 30 MHz PA assembly (1.6 to 30 MHz with
Option LF fitted)
Table 7 -6: Test channels for 2.25 to 30 MHz PA assembly
108-05237
Channel Frequency
MHz
PA LPF
range
Receiver
HPF
RF Amp Talk
Power
Select
Remarks
1 1.6 1.6-2.25 1.6-3.1 On Off Only with
2 2.0 option LF
3 2.2 fitted
4 2.3 2.25-3.45 2.0-3.1 On Off
5 2.8
6 3.4 3.1-4.8 On Off
7 3.5 3.45-5.35
8 4.5
9 5.3 4.8-7.47 On Off
10 5.4 5.35-8.2
11 7.0
12 8.1 7.47-11.6 On Off
13 8.2 8.2-12.65
14 10.2
15 12.6 11.6-18.0 On Off
16 12.7 12.65-
19.5
17 16.5
18 19.4 18.0-30.0 On Off
19 19.5 19.5-30
20 27
21 29.8
