Adjustments
HF SSB Transceiver 9323/9360/9390/9780 Technical Service Manual 7-9
Table 7-6 cont.
Channel Frequency
MHz
PA LPF
range
Receiver
HPF
RF Amp Talk
Power
Select
Remarks
22 1.6 1.6-3.1 On Off Receiver
23 3.1 3.1-4.8 HPF
24 4.8 4.8-7.47 check
25 7.5 7.47-11.6
26 11.6 11.6-18.0
27 18 18.0-30.0
28 26.5
29 2.3 1.6-3.1 Off On See note
40 19.999 18.0-30.0 On Off 90-20523-XXX
41 20.001 Ver 4.2 onward
©
Channel 29 (2.3 MHz) checks the transmit power with talk power on. Also the
receiver sensitivity can be measured with the RF amplifier off. All remaining
channels (1 to 28) have the talk power off. This allows the two-tone transmit
signal to be viewed on the oscilloscope without the ripple being displayed.
All channels have the following enabled:
• USB/LSB/AM
• Emergency Call
• Selcall
• Two-tone
