CONNECTING THE ELECTRICAL SERVICES
12. The mains cable fitted to the machine should be 3-core. The cable is terminated at mains
lead connection on the back of the machine. Connection to the electrical supply must not be
carried out using a cable with more cores than required.
13. Do not attempt to connect more than one heater to a 230V, 13A single phase supply. The
mains cable must be connected to the supply via a safety isolator switch, preferably located
behind the machine. Ensure that the supply to the isolator switch is isolated before making
the connections. Ensure that the supply to the beverage machine is isolated before making
any connections to the terminal block. The machine must be earthed.
14. Connect the beverage machine, via a safety isolator switch with a contact separation of at
least 3mm, to a 230V, 50Hz, 13A supply. Note that replacement of the Y Type mains cable
requires special tools. Should the cable become damaged, replacement must only be
carried out by a trained person from an approved service agent.
15. Preferably, the isolator switch should be located behind the machine to prevent accidental
damage or misuse.
16. The supply requirements, dependent on geography, are as follows.
• 1 heater operation (3kW/): 230V, 16A single phase, 50Hz
• 1 heater operation (2kW/): 230V, 10A single phase, 50Hz
17. The 3-core cable connections for 1 heater operation from a 230V, 10A/16A supply are as
follows:
LIVE BROWN
NEUTRAL BLUE
EARTH GREEN/YELLOW
Important: Where a beverage machine is to be connected to a 13A domestic socket
outlet, a 3-core power cable capable of carrying a minimum current of 13A, Part No.
54416, must be used. This cable is fitted as standard.
WARNINGS (1) THE MACHINE MAINS CABLE MUST BE CONNECTED TO THE SUPPLY
VIA A SAFETY ISOLATOR SWITCH WHICH PROVIDES A CONTACT
SEPARATION OF AT LEAST 3mm.
(2) REPLACEMENT OF THE Y TYPE MAINS CABLE REQUIRES SPECIAL TOOLS.
SHOULD THE CABLE BECOME DAMAGED, REPLACEMENT MUST ONLY BE
CARRIED OUT BY A TRAINED PERSON FROM AN APPROVED SERVICE
AGENT.
(3) ENSURE THAT THE SUPPLY TO THE ISOLATOR SWITCH IS ISOLATED
BEFORE MAKING ANY CONNECTIONS TO IT.
(4) ENSURE THAT THE SUPPLY TO THE BEVERAGE MACHINE IS ISOLATED
BEFORE MAKING ANY CONNECTIONS TO THE TERMINAL BLOCK AT THE
REAR OF THE MACHINE.
(5) THE BEVERAGE MACHINE MUST BE EARTHED.
