COFFEtek Neo + Technical Manual

COFFEtek Ltd
31
28/03/20
Issue 1
NEO TOUCH
(f) Cup Light Config
This menu gives access to allow the dispense area LED light sequencing to be
changed to a manor desired. The table below shows the sequences that the machine
can be set to run.
CONFIGURATION
IDLE
VEND
VENDED
1
OFF
OFF
ON
2
OFF
ON
ON
3
ON
OFF
ON
4
OFF
TOGGLE
ON
5
ON
TOGGLE
ON
6
OFF
OFF
OFF
7
ON
ON
ON
8
OFF
ON
OFF
9
ON
OFF
OFF
10
OFF
TOGGLE
OFF
11
ON
TOGGLE
OFF
MDB Config
12. This menu provides the means to modify parameters related to MDB peripherals connected
to the machine. However, as support for additional peripherals is added, so additional
settings will be added as appropriate.
The following table lists the submenus and parameters that are configurable:
PARAMETER
DESCRIPTION
MAX CREDIT
This monetary value defines the largest amount that can be accepted
by the mechanism. Once the displayed credit reaches the value set in
MAX CREDIT, no further coins will be accepted.
EXACT CHANG LIM
This monetary value represents the value of coins remaining in the
change tubes below which the EXACT CHANGE message is
displayed. Note for the audit system to work correctly, it is important
that all coins are inserted via the coin insert slot, i.e. not placed
directly in the change tubes.
VALIDATOR ESCROW
Provides the means by which an escrow capable validator is informed
which of the bills that it can accept should be held in escrow. As with
the coin accept masks for coin validators the bills are identified using
a 16-bit mask.
