Cognex CC24 - Specifications; Communication Card Specifications

Specifications
The following sections list general specifications for the Communication card.
Communication Card Specifications
Specifications Description
Bus Interface PCI Express, x1 Gen2
Bus Interface
Options
Any PCIe slot.
Inputs 8 optically isolated discrete inputs.
Outputs 16 optically isolated discrete outputs.
Encoder Inputs Four non-isolated 4x encoder inputs.
I-ENET Port 1 RJ-45 Ethernet port, 10/100 BaseT with auto MDIX. IEEE 802.3 TCP/IP Protocol. Dedicated port for
Ethernet-based industrial protocol communications.
Dimensions 168.0mm (6.6in) x 110.0mm (4.3in)
Power
Requirements
170 mA from PCIe bus +3.3VDC
240 mA from PCIe bus +12VDC
Power
Consumption
3.5W (maximum)
Power
Dissipation
1
9W (maximum)
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Storage
Temperature
-40°C to 65°C (-40°F to 65°F)
Humidity 10% - 90%, non-condensing (Operating and Storage)
Regulatory
Compliance
CE, FCC, KCC, RoHS
1
Current flow through optically-isolated I/O will dissipate additional power.
