Cognex CC24 - I-ENET Port

I-ENETPort
The I-ENET port is a 10/100 RJ-45 Ethernet port that can be connected to a network that is dedicated to industrial
Ethernet devices (for example, PLCs or robots) to communicate with the devices using supported industrial Ethernet
protocols.
Pin Number Signal Name
1 TRANSMIT+
2 TRANSMIT-
3 RECEIVE+
4 N/A
5 N/A
6 RECEIVE-
7 N/A
8 N/A
17
Specifications
