Cognex DM-280X - DataMan 280 Series Reader Image Sensor; Acquisition Trigger Input

Specification 280
Inputs
0 (Trigger), 1, 2, 3
V
IL
: ≤ ± 6 V
V
IH
: ≥ ± 12 V
I
TYP
: 4.2 mA @ 24 V
Ethernet 10/100/1000. Full duplex or half duplex.
DataMan 280 Series Reader Image Sensor
Specification Model
Image Sensor 1/3-inch CMOS, global shutter
Image Sensor Properties Diagonal dimension: 4.81 mm
Pixel area: 3.45 μm
2
Image Resolution (pixels) 1440 x 1080
Electronic Shutter Speed Minimum exposure: 29 μs
Maximum exposure: 10 ms (with internal illumination)
Maximum exposure: 200 ms (with external illumination)
Image Acquisition at Full
Resolution
Maximum: 45 Hz
Lens Type 6.2 mm (3 pos or HSLL), 16 mm (manual or HSLL), 6.2 mm UV, 6.2 mm and 16 mm IR,
C-Mount acc.
Acquisition Trigger Input
The reader features one acquisition trigger input, which is optically isolated. You can configure the acquisition trigger
input to trigger from an NPN (current sinking) or PNP (current sourcing) device.
l To trigger from an NPN type photoelectric sensor or PLC output, connect COMMON IN to +24 VDC and connect
IN 0 to the output of the photoelectric sensor. When the output turns ON, it pulls TRIGGER down to 0 VDC, turning
the opto-coupler ON.
l To trigger from a PNP photoelectric sensor or PLC output, connect IN 0 to the output of the photoelectric sensor
and connect COMMON IN to 0 VDC. When the output turns ON, it pulls TRIGGER up to +24 VDC, turning the
opto-coupler ON.
49
Specifications
