Cognex DM-280X - Dataman 280 Readers with a 16 MM Lens

Long Range (Focused to 190 mm)
The following section shows the Field of View (FoV) widths of the 6.2 mm lens focused to 190 mm at various distances.
Working distance in mm Horizontal values in mm Vertical values in mm
Z
1
= 190 X
1
= 159 Y
1
= 119
Z
2
= 225 X
2
= 187 Y
2
= 140
Z3 = 375
X
3
= 307 Y
3
= 230
Z
4
= 1000 X
4
= 808 Y
4
= 606
Distances in mm 2D min. code in mil 1D min. code in mil
150 10 6
190 12 8
225 15 8
375 20 15
500 30 20
1000 60 35
DataMan 280 readers with a 16 mm lens
The following section shows the Field of View (FoV) widths of the 16 mm lens at various distances.
22
Setting Up Your DataMan Reader
