5. LCD Operation Instruction
5.1 Operation Instruction
Knob/OK:
⚫ In the main interface, press the knob/OK to enter the operation menu;
⚫ On the operation menu, rotate the knob to scroll to a menu item, press the knob/OK to
select the current item or enter the submenu;
⚫ Rotate the knob to adjust parameters after selecting the menu item with the parameter
and press the knob/OK to save the parameter.
ESC: Exit the current menu or operation.
Bright: Press the key and rotate the knob to adjust screen brightness, and then press the
knob/OK to confirm the current brightness.
Black: Blackout.
Lock: Lock all the keys of the front panel. You can press it again and follow the directions to
press OK to exit Lock mode.
Mode: Switch to the interface of fast loading preset parameters.
Freeze: Freeze the image.
DVI1/DVI2/DVI3/DVI4/SDI1/SDI2/HDMI: Video source selection keys, which function as
number selection keys in the mode selection.
