ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
6.10 m
36.58 m
1.98 m
5.23 m
2.59 m
1.04 m
AIR INLET HAZARD AREA
DURING GROUND IDLE
AIR INLET HAZARD AREA
DURING TAKEOFF THRUST
EXHAUST HAZARD AREA
DURING GROUND IDLE
EXHAUST HAZARD AREA
DURING TAKEOFF THRUST
105 km/h
9.45 m
105 km/h
)
114.91 m
R(GROUND IDLE ) =
R(TAKEOFF THRUST) =
ICN-ARJ21-A-710000-A-SVV19-05442-A-003-01
Figure2Enginegroundsafetyprecautions(Sheet1of1)
ARJ21-A-13-12-11-01A-030A-A
Issue001,2023-01-29
Applicableto:ALL
Page3of4
