SEA LEVEL
STANDARD ATMOSPHERE
20 kt (10.2 m/s) HEADWIND
STATIC AIRPLANE
DISTANCE FROM AIRPLANE CENTERLINE
FEET
METER
AXIAL DISTANCE BEHIND AIRPLANE
GROUND CLEARANCE
EXHAUST TEMPERATURE HAZARD AREAS − IDLE THRUST
KEEP−OUT ZONE
(VELOCITY = 65 MPH (29 m/s))
36 ft (11 m) BEHIND AIRCRAFT
EXHAUST VELOCITY HAZARD AREAS − DLE THRUST
SEA LEVEL
STANDARD ATMOSPHERE
20 kt (10.2 m/s) HEADWIND
DISTANCE FROM AIRPLANE CENTERLINE
METER
FEET
AXIAL DISTANCE BEHIND AIRPLANE
GROUND CLEARANCE
WITH GROUND EFFECTS
(ASSUME ENGING
CENTRELINE TO GROUND
=123 in (3124 mm))
