COMAC ARJ21-700 - Page 176

ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
SwitchNamePosition/Status
LHTANKCLOSEDOff
RHTANKCLOSEDOff
DEFUELINGOPENOff
(c)Removetherefuel/defueladaptercapinthefwdrefuelcompartmentattherightwingfront
spar.
(d)Doaninspectionoftherefuel/defueladapterbeforeyouconnecttherefuelnozzle.
1)Makesurethattherearenofuelleaks.
2)Makesurethatthematingsurfacebetweentherefuelnozzleandrefueladapteris
freefromunwantedmaterialandnotdamaged.
3)Makesurethatthecapbindingwireisnotmissingordamaged.
(e)Connecttherefuelnozzletotherefuel/defueladapter.Rotatethehandleattheendofthe
refuelnozzletoopentheshutoffvalve.
(f)Pressurizetherefuelingsystemto35psi～50psi(241.3kPa～344.7kPa).
NOTE:
Refuelingunderalowerpressureisallowed,however,itwilltakemuchlongertime.
(g)Makesurethatthereisnofuelowatthistime,andtheannunciatorsontherefuel/defuel
controlpanelshowasfollows(precheckoftheshutofffunction):
SwitchNamePosition/Status
LHTANKCLOSEDOn
RHTANKCLOSEDOn
DEFUELINGOPENOff
CAUTION:CHECKTHELEFTANDRIGHTFUELTANKSFORFUELOVERFLOWDURING
THEREFUELINGPROCESS.EXCESSIVEREFUELINGWILLCAUSEFLOW-
INGOFUNWANTEDFUELTOTHENACAVENTANDDAMAGETOTHEAIR-
FRAMESTRUCTURE.
(h)SettheLHTANKREFUELINGandRHTANKREFUELINGswitchestotheOPENposition.
MakesurethattheLHTANKandRHTANKrefuelshutoffvalveCLOSEDannunciatorsare
offandtherefuelingoperationisstarted.
(i)Stoptherefuelingoperationwhenthetargetquantityoffuelisreached.Makesurethatthe
LHTANKandRHTANKrefuelshutoffvalveCLOSEDannunciatorsareon.
(j)Stoptherefuelingoperation.
(k)SettheLHTANKREFUELINGandRHTANKREFUELINGswitchestotheCLOSEDpo-
sition.
(l)MakesurethatthePOWERSELECTIONswitchisintheNORMALposition.
(m)Rotatetheshutoffvalvehandleoftherefuelnozzletotheclosedposition,disconnectthe
refuelnozzlefromtherefuel/defueladapter.
(n)Installtherefuel/defueladaptercapontherefuel/defueladapter.
(o)Removeanyspilledfuelattherefueladapter,withadrycottonclothwipe.
ARJ21-A-13-12-18-03A-211A-A
Issue001,2023-01-29
Page4of6
Applicableto:ALL
