ComAp IG-NT - Page 209

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
209
by the binary input ExtValue4reset.
Setpoint: ExtValue4LoLim
Group
Force value
Range [units]
-32000 .. ExtValue4HiLim [X]
Related FW
3.0
Description
This setpoint adjusts the low limit of the value of ExtValue 4 if the value is
lowered/raised by the binary inputs ExtValue4 up and ExtValue4 down. The
ExtValue 4 is never lowered below this limit.
NOTE:
This limit is not taken into account if the value ExtValue 4 is written remotely from
a terminal using the appropriate command ExtValue #n.
NOTE:
For IS-NT only.
Setpoint: ExtValue4HiLim
Group
Force value
Range [units]
ExtValue4LoLim .. 32000 [X]
Related FW
3.0
Description
This setpoint adjusts the high limit of the value of ExtValue 4 if the value is
lowered/raised by the binary inputs ExtValue4 up and ExtValue4 down. The
ExtValue 4 is never raised over this limit.
NOTE:
This limit is not taken into account if the value ExtValue 4 is written remotely from
a terminal using the appropriate command ExtValue #n.
NOTE:
For IS-NT only.
Setpoint: ExtValue4 rate
Group
Force value
Range [units]
1 .. 10000 [X/s]
Related FW
3.0
Force value
possible
YES
Force value
possible
YES
Description
This setpoint adjusts the rate pre second at which the ExtValue 4 is beeing
changed while the input ExtValue4 up or ExtValue4 down is active.
Group: Load shedding
