IGS-NT Communication Guide
64
5.1.3 InteliVision 5 display
Controllers
Controllers IG-NT-BB IM-NT-BB IG-NTC-BB IS-NTC-BB IM-NTC-BB
Connectionapplicable YES YES YES YES YES
Physical port RS485 (1) RS485 (1) RS485 (1) RS485 (1) RS485 (1)
More info
IG/IM-NT-BB - Terminal
(page 17)
IG/IS/IM-NTC-BB - Terminals (page 13)
Controllers IG-NT IM-NT IG-NTC IS-NT-BB
Connectionapplicable YES YES YES YES
Physical port RS485 (1) RS485 (1) RS485 (1) RS485 (1)
More info IG/IM-NT-BB - Terminal (page 17)
IG/IS/IM-NTC-BB - Terminals (page
13)
It is possible to connect up to 3 InteliVision 5 displays to RS485(1) terminal Link (IG/IS/IM-NTC-BB -
Terminals (page 13)).
Note: Connection InteliVision 5 to IG/IS-NT controllers is described in InteliVision5 Global Guide.
Controller setup
(Setpoints/Comms settings group)
RS485(1) conv. = DISABLED
5.2 Comms extension - I-LB+ Local bridge
I-LB+ is communication modules for communication with all devices connected to CAN(2) bus. I-LB+ is
successors of the IG-MU unit designed to be used with IG/IS controllers. It therefore provides additional
communication port and higher communication speed. Speed for direct/modem connection can be up to 57600
bps. I-LB+ can be connected with PC via USB, RS232 or RS485. I-LB+ is with USB port (speed ≈ 115200 bps).
