Communication Guide, ©ComAp – March 2014 141
IGS-NT Communication Guide 03-2014.pdf
53 44 = Object data value (S D)
20 31 = Object data value (_ 1)
32 00 … = Object data value (2) = > 1.record in alarmlist is *Sd SD 12 (inactive, not accepted)
F5 18 = CRC
Response: 01 03 32 21 2A 53 64 20 53 44 20 31 32 00 00 … 00 00 89 38
01 = Controller address
03 = Modbus function code (Read Multiple Registers)
32 = Length of read data in Bytes (in HEX)
21 2A = Object data value (! *)
53 64 = Object data value (S d)
20 53 = Object data value (_ S)
44 20 = Object data value (D _)
31 32 … = Object data value (1 2) = > 1.record in alarmlist is !*Sd SD 12 (active, not accepted)
38 89 = CRC
Change the communication language (only String type data)
Write to the communication object 6350 the index of language to be used.
A part of dedicated communication objects table
Registers (*)
Register
addresses (*)
Number of
registers
Access
Data type
Meaning
46349 – 46350
6348 – 6349
2
read/write
Date
Actual date
46351
6350
1
read/write
Unsigned8
Language index selected for displaying of texts
specified by data type String (# 7)
46352 – 4653
6351 – 6352
2
read
Domain
Code of the last communication fault
See Error list
46354
6353
1
read
Unsigned8
Number of records in the alarm list
46349 – 46350
6348 – 6349
2
read/write
Date
Actual date
46351
6350
1
read/write
Unsigned8
Language index selected for displaying of texts
specified by data type String (# 7)
Request: 01 06 18 CE 00 01 2F 55
01 = Controller address
06 = Modbus function code (Write Single Register)
18 CE = Register address: Register number (46351) – 40001 = 6350 DEC => 18CE HEX
00 01 = Set the language index to > 1
55 2F = CRC (write LSB MSB !)
Response: 01 06 18 CE 00 00 EE 95
01 = Controller address
06 = Modbus function code (Read Multiple Registers)
18 CE = Register address
00 01 = Language index set to > 1
55 2F = CRC
