IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
NOTE:
There isn't any relation between the default names of the force value function
blocks, associated binary inputs and the default names of the reserved setpoints.
In other words, the setpoint with default name Force value 3 is not related to the
Force value 3 function block.
Setpoint: ExtValue1deflt
This setpoint adjusts the reset (initial) value of the ExtValue 1. This initial value is
applied either when the controller is powered-on or when the ExtValue 1 is reset
by the binary input ExtValue1reset.
Setpoint: ExtValue1LoLim
-32000 .. ExtValue1HiLim [X]
This setpoint adjusts the low limit of the value of ExtValue 1 if the value is
lowered/raised by the binary inputs ExtValue1 up and ExtValue1 down. The
ExtValue 1 is never lowered below this limit.
NOTE:
This limit is not taken into account if the value ExtValue 1 is written remotely from
a terminal using the appropriate command ExtValue #n.
NOTE:
For IS-NT only.
Setpoint: ExtValue1HiLim
ExtValue1LoLim .. 32000 [X]
This setpoint adjusts the high limit of the value of ExtValue 1 if the value is
lowered/raised by the binary inputs ExtValue1 up and ExtValue1 down. The
ExtValue 1 is never raised over this limit.
NOTE:
This limit is not taken into account if the value ExtValue 1 is written remotely from
a terminal using the appropriate command ExtValue #n.
NOTE:
