COMBISAFE System Mk II - Fall Clearance Essentials

Loading System MkII Safety Instructions
7
Fall clearance
Note that it is essential to verify that adequate free height exists to the closest
underlying object, please see Figure 2 below.
A
A+B
A+B
C
Figure 2. Explanation of fall clearance.
A: 0,7 [m] Maximum vertical deflection of the SkyReach Anchor Point
B: X Braking distance of the SRL. Please refer to the
manufacturer´s user instructions for specific values.
C: 1 [m] Safety distance.
Total required fall clearance = A+B+C
