TO THE PC
E.G. 192.168.0.30
During the system scan...
f
h
i
g
e
PERFORM A DHCP SYSTEM SCAN AND ASSIGN A ViP ADDRESS
Follow the procedure below to perform a system scan in “DHCP”, to locate all the devices connected to interfaces A and B:
• an IP address will be automatically assigned to the devices in addressing mode “Autoip” (connected to interface B);
• an IP address will be automatically assigned to the devices in addressing mode “DHCP” (connected to interface A), if the
system is connected to a server with the function active;
• devices with “Static IP address” will be identified only if they have a network address that is compatible with that of
interface A.
1. From Options [a] / Local connections [b] tick DHCP Enable [c] and confirm [d].
2. Launch the system scan by pressing Scan System [e].
» all the devices connected to the system will be displayed in the device list.
3. Select the device 1456 B [f], select Addressing/ViP address [g], assign an unequivocal ViP address to the device [h] and
press Write page [i] to save the current settings.
