Comelit 1456B - System with Single Network

7
INTERFACE A
STATIC IP ADDRESS
192.168.1.200 (default)
40-56 Vdc
B
+
-
A1
ONLY WITH COMELIT RED CABLE 2E7T000500
ONLY WITH COMELIT RED CABLE 2E7T000500
FIXED POE
SETTABLE POE
NON POE
A2 A3 A4
Art 1456B
t.
ROUTER
Art.1441
Art.1441B
ViP SYSTEM
Installer PC
with ViP Manager
version 2.5.0 and higher
with active
internet connection
INTERNET
SIP
PROVIDER
All system devices form part of a single network, so it it is only necessary to configure interface A.
In this case, DO NOT the alter the configuration of interface B.
SYSTEM WITH SINGLE NETWORK
