Comelit 1456B - Settable POE

4
1441
1441B
PoE
NON PoE NON PoE
PoE
Max 1 PoE
40-56 Vdc
B
+
-
A1
SOLO CON CAVO ROSSO COMELIT 2E7T000500
ONLY WITH COMELIT RED CABLE 2E7T000500
FIXED POE
SETTABLE POE
N0 POE
A2 A3 A4
40-56 Vdc
B
+
-
A1
SOLO CON CAVO ROSSO COMELIT 2E7T000500
ONLY WITH COMELIT RED CABLE 2E7T000500
FIXED POE
SETTABLE POE
N0 POE
A2 A3 A4
1440
CV1
CV2
CV3
CV4
With the device powered by Art. 1440 via port B, there will be sufficient PoE power available to operate a
maximum of 1 door as “POE” on port A1, A2 or A3.
Settable POE
SETTABLE POE
A2 A3
DEFAULT
CV1 CV2 CV3 CV4
CV1 CV2 CV3 CV4
NON POE
STANDARD ETHERNET
CV1 CV2 CV3 CV4
CV1 CV2 CV3 CV4
NON POE
STANDARD ETHERNET
SETTABLE
CV1 CV2 CV3 CV4
CV1 CV2 CV3 CV4
POE
DO NOT USE STANDARD ETHERNET
Only connect to the router or
PC using the red Comelit cable
2E7T000500
CV1 CV2 CV3 CV4
CV1 CV2 CV3 CV4
POE
DO NOT USE STANDARD ETHERNET
Only connect to the router or
PC using the red Comelit cable
2E7T000500
